Drawing Conversion Services

We can take care of the final deliverables so you can focus on designing

We specialise in Autocad DWG to Microstation DGN conformance for BHPIO, Rio Tinto and Western Power

Request a quote

Compliance and delivery of design and as-built drawings

THE SITUATION

  • You have bid for all or part of a project from a major Australian mining company or government department/utility
  • Your bid is selected by the client or prime-contractor
  • You are required to supply a) design drawings for approval before you can start work and b) as-built drawings afterwards in order to receive payment
  • You are given rigid specifications for the format, composition and titleblocks.
  • Your regular drafting source doesn’t do that format – maybe the drawings need to be in MicroStation and you are using Autocad for example

Your choices:

EITHER

  • Acquire and ramp-up all the appropriate software and design tools for this client, usually this will include the CADconform software from Corporate Montage which is specified by many of the major operators

OR

  • Use Corporate Montage’s Drawing Conversion service and be guaranteed compliant drawings for on–time delivery. We are the creators of CADconform so expect a high standard of compliance! For a typical set of drawings we’ll offer a 14 day turnaround and attractive price when compared with the alternatives.



More info – email info@corporatemontage.com or call us on 08 9221 7375, note we will need to see all the native files and PDFs ahead of time to give you a quotation.

Stop Fixing Drawings. Start Preventing Problems.
